SKYLOTEC PILLAR SG carabiner
Country of origin: Italy
Article MPN: H-285
MBS 24 kN || Weight 75 g || Clearance 21 mm
Do you need advice?
Skyman = certified manufacturer
We splice ropes with a TÜV certificate
> 20 years in the industry
Products tested in the field!
More than just sales!
Service, PPE inspections, testing & trainings.
Showroom Brno
> 5000 products in stock.
Variants1
| Color | Availability | Price | Quantity (pc) | |||
|---|---|---|---|---|---|---|
 |
black |
In Stock
20 pc in stock
|
More |
13,04 $
13,04 $ excl. VAT
|
Product Description
D-shaped aluminum carabiner with screw cap, max. gate opening of 21 mm
- Special: Developed for positioning devices with a large cross-section
- Optimized: Ideal for stance use as well as recovery and rescue maneuvers
- Safe: Catch-free closure prevents unintentional entanglement during use
| Parameter | Specification |
|---|---|
| Anti-twist device | No |
| Application areas | Various |
| Brand | SKYLOTEC |
| Carabiner properties | Corrosion resistance |
| Carabiner type | Type B (EN 362:2004), Type B (EN 12275:2013) |
| Fall indicator | No |
| Form fit | Key Lock |
| Gate opening | 21 mm |
| MBS Gate Open | 7 kN |
| MBS Major Axis | 24 kN |
| MBS Minor Axis | 10 kN |
| Material | Aluminium |
| Maximum lifetime | 30 years |
| Maximum temperature | 45 °C |
| Minimum temperature | -35 °C |
| UIAA compliance | Yes |
| Usable in SEAL PAC | Not rated |
| Colour | black |
| Customs tariff number | 76169990 |
| E-class number | 40-21-07-12 |
| Gross weight | 0.08 kg |
| Locking mechanism | Screwgate |
| Net weight | 0.08 kg |
| Standards | EN 362:2004/B, EN 12275:2013/B, UIAA 121 |
Specifications
| Article MPN | H-285 |
|---|---|
| Color | black , orange |
| Certification | UIAA 121 , EN 362:2004/B , EN 12275:2013/B |
| Weight | 75 g |
| Material | dural |
| Breaking load (MBS) | 24 kN |
| MBS (Gate Open) | 7 kN |
| MBS (Major Axis) | 10 kN |
| Dimensions | 111 x 62 mm |
| Gate opening | 21 mm |
Manufacturer/Importer information
| Manufacturing company | SKYLOTEC GmbH |
|---|---|
| Address | Im Mühlengrund 6-8, 56566 Neuwied - Germany |
| info@skylotec.com |
Download
SKYLOTEC PILLAR SG product sheet (pdf, 267.1 kB)
SKYLOTEC General Instructions (pdf, 3.2 MB)
SKYLOTEC PILLAR SG manual (pdf, 2.1 MB)
SKYLOTEC PILLAR SG Declaration of Conformity (pdf, 470.2 kB)
