The lowering bollard is ideally used with ropes of 14 mm diameter.
It can be easily installed on the tree by a single person, as it weighs only 4.4 kg.
Two rubber pads protect the tree trunk from damage.
Option to attach an anchor sling below the bollard to prevent movement on the trunk – recommended.
The straps are equipped with hooks with safety pins, which can only be removed when not under load.
The straps allow use on trunks up to 145 cm in diameter.

Color: blue
Max. strength (MBS): 2000 kg
Max. working load (WLL): 1000 kg
Max. rope diameter: 14 mm
Weight with rubber pads: 4.4 kg
Weight with pads and strap: 5.8 kg
Bollard dimensions: height – 210 mm, width – 310 mm (see image)
Central shaft dimensions: diameter – 73 mm, length – 140 mm (see image)
Material: galvanized steel
Surface treatment: powder coating
Certification: EN 121952:2001

Equipment:
- 1x lowering bollard SMB1000
- 1x ratchet (width - 50 mm strength - 6000 kg)
- 1x strap 4.65 m
- 1x pair of rubber pads
